Technical Specifications

Warranty Lifetime

Number of Conductors 20

Connector Plating Gold

Cable Jacket Type PVC - Polyvinyl Chloride

Cable Shield Type Aluminum-Mylar Foil with Braid

Connector A 1 - DisplayPort (20 pin) Male

Connector B 1 - DisplayPort (20 pin) Female

Color Black

Wire Gauge 28 AWG

Max Connector Dimension 0.8 in [20.4 mm]

Cable Length 6 in [152.4 mm]

Cable OD 0.3 in [7.3 mm]

Product Weight 1.3 oz [38 g]

Shipping (Package) Weight 2.5 oz [70 g]

Included in Package 1 - 6in DisplayPort port extension
